Crown Jewel III
Model number: BLCJ18-3
With an 18-inch throat space, the Crown Jewel III is the most popular size in longarm quilting machines and is ideal for quilters looking for more workspace and software. This feature-rich machine sews at an impressive 2,200 stitches per minute, while its built-in stitch regulator and Precision Stitch mode ensure smooth, precise stitching, even after hard stops and pauses.
The Crown Jewel III also includes a new quick-set tension that allows you to easily adjust upper thread tension and view your settings on the digital LCD readout. Additionally, its enhanced LED light ring better illuminates the needle area – where you need light most.


Crown Jewel III Brochure



Back to top

Features



18" Workspace
As a longarm machine, the Crown Jewel III’s larger workspace allows you to stitch freely without worrying about limitations.





Back and Front Handles
Effortlessly control the motion of the Crown Jewel III from either end of the machine with the comfort-grip handles. Options are right at your fingertips with push-button controls. Change the stitching speed, start and stop the Crown Jewel III, or place the needle up or down with buttons directly built into the handles.





LCD Display
Set and easily read Stitch Control Features with the large, color LCD displays on both ends of the machine. Change settings, lighting and speed with minimal scrolling. You can set your preferred needle speed for the Manual Stitch Mode. Plus, a digital readout allows you to monitor upper thread tension settings.





Built-In Stitch Regulator
Stitching has never been smoother than with the Crown Jewel III. The Precision Stitch mode allows you to make hard pauses without interruption and regulates the selected stitch length. The Cruise Stitch regulated mode allows the needle to immediately begin stitching at the precise speed chosen while regulating your stitch length.





Large "M" Class Bobbin
Enjoy fewer bobbin changes with the largest bobbins available in quilting (up to 40% larger than a standard bobbin). Plus, the low bobbin estimator warns you before your bobbin runs out. And with the variable speeds on the electric bobbin winder, you can easily wind thread of different types and weights.



Back to top


Specifications

Technical Features

18" wide workspace to right of needle x 8.25" high
Stitch Control Features for perfectly balanced stitches

1/4" Hopping foot holds down the fabric while the needle completes the stitch
Needle bar stroke = 35.3mm
Hopping foot stroke/lift = 5mm


Manual Stitch Mode allows manual operation of the machine at a pre-selected needle speed
Stitch Regulator is built-in and regulates your selected stitch length from 4 to 18 stitches per inch

Precision Stitch regulated mode follows your lead and is best for ruler work and tracing patterns
Cruise Stitch regulated mode allows the needle to immediately begin stitching at the percent speed chosen


Quick-Set Tension makes setting upper thread tensions and remembering tension settings easier
Automatic Needle Positioning:

Needle Up/Down
Full Stitch and Half Stitch - programs the needle to take a half stitch or full stitch when the needle up/down button is pressed


Basting options in both Cruise and Precision modes allow you to baste layers every 1/2", 1", 2" or 4"

Walking Stitch for tie off stitches at the beginning and end of quilting


Maximum sewing speed of 2,200 spm

Save your preferred speed settings with three customizable presets


Front and Back Handles for easy control and less fatigue

Provides control from 2 sides of the machine
Easy-to-reach rubber grips for comfort


Large, color LCD Display shows:

Stitch Regulator and Manual modes
Multiple LED Lighting options
Memory settings
Needle speed
Alarm mode
Calculator
Timers
Program settings
Stitch counters
Diagnostics
Low bobbin estimator


Handle Bar Control Buttons at your fingertips

Needle Up/Down
Start/Stop
Speed Up
Speed Down


Front Power Switch for easy access
Uses 134R system, slight ball point needle
High-speed rotary hook
"M" Class Bobbin

Low bobbin estimator warns you when you are running low on bobbin thread
Store three bobbin thread capacity settings based on your preferred thread


External electric bobbin winder with variable speeds lets you wind your own "M" bobbins with personally selected threads
Laser light stylus for ease in following pantographs from front or back of machine
Two Timers

Reminder can be set to alarm after a period of time
Project timer tracks time spent on a quilt project


Lighting

Integrated high intensity natural-color LED lights on front handle bar (12 light clusters x 3LED/cluster =36 LED lights & 4 UV Lights x 3 LED/cluster =12 UV LED Lights)
Ability to add up to 8 more clusters


Can use patterns, stencils, threads, 1/4" thick rulers and templates that commercial quilters use



Additional Information

4 Languages (English, Spanish, French, German)
Quiet/smooth operation

Solid cast aluminum construction
Internal DC motor


Machine weight with handles - 68 lbs.
Made in the U.S.A. of globally sourced parts
Warranty: 10-year casting parts, 5-year parts, 5-year circuit boards, 5-year electrical, 90-day labor
Ask your Baby Lock Retailer about machine maintenanc



Optional Accessories

Momentum Frame - Item #BLQM
Momentum Frame 2-foot extension - Item #BLQM-EXT
Momentum Frame Casters - Item #BLQM-CASTER
Pearl Frame - Item #BLQF
Pearl Frame 2-foot extension - Item #BLQF-EXT
Pro-Stitcher Quilting Software - Item #BLPS3
Quilter's Creative Touch Software - Item #BLCJ18-QCTS
Quilter's Creative Touch & QuiltMotion Software Combo- Item #BLJ18-QMQCTS
Micro Handles - Item #BLJ18-MH
Ruler Base - Item #BLJ18-RB
Horizontal Spool Pin - Item # BLJ18-HS
Cluster Light - Item #BLJ18-L
UV LED Lights -Item #BLJ18-UVL
Love of Sewing Membership - Item #BLCJ-LOSM
Baby Lock Leader Cloths - Item #BLQL
Grace Start Right Cloth Leaders - Item #GFCL & GFCL-12
Adapter & Stylus Holder - Item #BLJ18-SA
Stylus - Item #BLJ18-ST
Channel Lock - Item #BLJ18-CL
Bobbins - Item #BLJ-BOB
Needles:

Size 12 - Item #134FG-80
Size 14 - Item #134FG-90
Size 16 - Item #134FG-100
Size 18 - Item #134FG-110
Size 20 - Item #134FG-125






Back to top

Accessories Included


Carriage with encoders for Pearl or Momentum Frame
Electronic bobbin winder with variable speed
Laser light and clamp
Other Accessories:

5 "M" size metal bobbins
Interchangeable Open Toe Hopping Foot
2 packs of needles (size 16 and 18)
Thread mast and washers
Oiler
Wrenches and screwdrivers
Cleaning brush
Instruction manual
